In any septic tank installation, there are two components that often go unnoticed but are essential for preventing blockages and breakdowns:
👉 inlet and outlet baffles.
At Limpiezas Domingo, with over 15 years of experience in septic tank maintenance and emptying in Dénia, Jávea and Calpe, we explain what these elements are for, how they work and why they should be checked periodically.
What are septic tank baffles?
The inlet and outlet deflectors are pipes or elbows installed inside the tank, right where the wastewater enters and exits.
Their function is to direct the flow so that solids settle properly and do not pass into the filtration system or the absorption well.
Imagine the pit as a tank divided into layers:
-
Grease and oil (foam) accumulate on the surface.
-
At the bottom, the heaviest sludge.
-
In the centre, the partially clarified water is directed towards the outlet.
Without deflectors, turbulent currents can carry solids into the drain, causing blockages in the pipes or in the infiltration field.
Function of the inlet deflector
The inlet deflector distributes the flow of wastewater from the dwelling to the bottom of the tank.
It prevents water from entering with too much force, which could stir up sedimented sludge or damage the internal biological process.
🔹Key benefits:
-
Reduce the impact of incoming flow.
-
Promotes the separation of solids and liquids.
-
Extends the service life of the system.
When the inlet deflector becomes blocked, debris accumulates in the main pipe, causing a progressive blockage.
In this case, we recommend cleaning the pipes with pressurised water using a professional tanker truck.
Output deflector function
The outlet deflector — also called the outlet tee or discharge elbow — has an equally important mission:
to prevent suspended solids or fats from escaping into the filtration field.
This submerged pipe collects only the clarified water from the centre of the tank and directs it towards the drainage system.
This prevents grease, paper or floating matter from reaching the ground or the biological filter.
🔹 If the outlet deflector fails:
-
Obstructions may occur at the outlet.
-
Water can carry debris that clogs the drain or filter well.
-
The system’s useful life is shortened and unpleasant odours increase.
💡 A broken or missing baffle is one of the most common causes of failure in domestic septic systems.
How to detect problems with deflectors
During septic tank maintenance, Limpiezas Domingo technicians carry out a visual inspection or CCTV camera inspection, checking:
-
If the deflectors are correctly positioned.
-
If there are cracks, corrosion or blockages.
-
If the height of the tube is adequate for the liquid level.
A camera inspection service allows any anomalies to be detected without having to open or empty the system.
Maintenance tips to prevent blockages
-
Check the pit every 12 to 24 months.
-
Do not pour aggressive chemicals into the system.
They can damage the natural bacteria that carry out the purification process.
The Ministry for Ecological Transition recommends using biological additives if necessary. -
Clean the tank when the sludge reaches 50% of its volume.
This is the ideal time for professional emptying with a tanker lorry. -
Avoid disposing of wipes, grease, or oils.
These are the main causes of blockages in deflectors and pipes. -
Check the ventilation.
Lack of ventilation can increase pressure and disrupt internal functioning.
Replacement and repair of deflectors
Sometimes, deflectors can break due to corrosion, roots or ground movement.
At Limpiezas Domingo, we have technicians who specialise in repairs without construction work, who can replace damaged components without having to excavate or replace the entire tank.
🔧 Timely repairs can save hundreds of pounds in renovations and prevent polluting spills.
Service coverage
We carry out maintenance, cleaning and repair of septic tanks throughout the Marina Alta and La Safor regions:
📍 Dénia, Jávea, Calpe, Benissa, Moraira, Teulada, Ondara, Oliva and Gandía.
We offer a 24-hour emergency service and scheduled maintenance for communities, housing developments and private individuals.
💬 Frequently asked questions about septic tank baffles
What happens if a deflector breaks?
The system loses its balance and solids can flow into the drain, causing blockages and unpleasant odours. It is essential to repair it as soon as possible.
Can I check the deflectors myself?
Only if you have experience and adequate safety measures. Otherwise, contact professionals, as cesspits emit dangerous gases.
How often are the deflectors checked?
During routine maintenance of the septic tank (every 1–2 years). It is advisable to take advantage of the emptying to check them.
Can they be replaced without breaking the pit?
Yes. There are repair methods that do not require construction work, allowing deflectors to be replaced from the inspection hatch.
Which materials are most durable?
PVC or high-density polyethylene deflectors offer high resistance to corrosion and continuous use.
